WARNING:
The
fan
trays
use
a
double
latch
safety
mechanism.
You
must
continually
press
and
hold
the
latch
while
removing
the
fan
trays.
5.
Place
each
component
on
an
antistatic
mat
resting
on
a
stable,
flat
surface.
CAUTION:
Do
not
stack
fan
trays
on
one
another
after
you
remove
them.
Figure
94:
Removing
Upper
Fan
Trays
g007036
Figure
95:
Removing
Lower
Fan
Trays
g007039
252
271
273
