CAUTION: The weight of the CB-RE is concentrated in the back end. Be
prepared to accept the full weight—up to 15 lb (6.8 kg)—as you slide the CB-RE
out of the chassis.
When the CB-RE is out of the chassis, do not hold it by the ejector handles, bus
bars, or edge connectors. They cannot support its weight.
CAUTION: Do not stack CB-REs on one another after you remove them. Place
each component on an antistatic mat resting on a stable, flat surface.
Figure 98: Removing a CB-RE
g007029
19
0
OK/FAIL
OK/F
AIL
OK/FAIL
OK/F
AIL
OK/FAIL
OK/FAIL
OK/FAIL
OK/FAIL
RELATED DOCUMENTATION
Preventing Electrostatic Discharge Damage to an MX2020 Router
Overview of Preparing the Site for the MX2020 Router | 121
257
