Figure
115:
Reinstalling
a
DC
Power
Distribution
Module
(240
V
China)
8
6
g100403
NOTE:
For
the
DC-powered
router,
make
sure
the
switch
is
set
to
60
A,
or
80
A
to
match
the
DC
circuit
input
feed.
This
does
not
apply
to
the
240
V
China
DC
PDM.
SEE
ALSO
Removing
the
Power
Distribution
Modules
Before
Installing
an
MX2020
Router
in
a
Rack
280
299
301
