3. Carefully align the sides of the CB-RE with the guides inside the chassis.
4. Slide the CB-RE into the chassis until you feel resistance, carefully ensuring that it is correctly aligned.
5. Grasp both ejector handles, and gently close them inward simultaneously until the CB-RE is fully seated.
6. Check the LEDs on the CB-RE faceplate to verify that it is functioning normally.
•
The green OK/FAIL LED should light steadily a few minutes after the CB-RE is installed.
•
If the OK/FAIL LED is red, remove and install the CB-RE again. If the OK/FAIL LED still lights steadily,
the CB-RE is not functioning properly. Contact your customer support representative. See “Contacting
Customer Support” on page 705.
7. Check the status of the CB-RE by using the show chassis environment cb command:
user@host> show chassis environment cb
CB 0 status:
State Online Master
IntakeA-Zone0 Temperature 25 degrees C / 77 degrees F
IntakeB-Zone1 Temperature 29 degrees C / 84 degrees F
IntakeC-Zone0 Temperature 28 degrees C / 82 degrees F
ExhaustA-Zone0 Temperature 26 degrees C / 78 degrees F
ExhaustB-Zone1 Temperature 28 degrees C / 82 degrees F
TCBC-Zone0 Temperature 32 degrees C / 89 degrees F
Power 1
1.0 V 1008 mV
1.2 V 1208 mV
1.8 V 1801 mV
2.5 V 2526 mV
3.3 V 3312 mV
5.0 V 5020 mV
5.0 V RE 4995 mV
12.0 V 12123 mV
12.0 V RE 12007 mV
Bus Revision 100
FPGA Revision 271
CB 1 status:
State Online Standby
IntakeA-Zone0 Temperature 30 degrees C / 86 degrees F
IntakeB-Zone1 Temperature 25 degrees C / 77 degrees F
IntakeC-Zone0 Temperature 39 degrees C / 102 degrees F
ExhaustA-Zone0 Temperature 33 degrees C / 91 degrees F
ExhaustB-Zone1 Temperature 28 degrees C / 82 degrees F
TCBC-Zone0 Temperature 31 degrees C / 87 degrees F
