Juniper MX2020 Hardware Guide

PIC 3 BUILTIN BUILTIN 10x 1GE(LAN) SFP
Xcvr 0 REV 01 740-011613 P9F13CH SFP-SX
Xcvr 1 REV 01 740-011782 PAR1L2E SFP-SX
Xcvr 2 REV 01 740-011782 P9M0TLC SFP-SX
Xcvr 3 REV 01 740-011613 PAM6KBK SFP-SX
Xcvr 4 REV 01 740-011613 PAM3WLY SFP-SX
Xcvr 5 REV 02 740-011613 PFQ4NUW SFP-SX
Xcvr 6 REV 02 740-011613 AM1003SFUZH SFP-SX
Xcvr 8 REV 02 740-011613 AM1033SH2MQ SFP-SX
Xcvr 9 REV 01 740-031851 AM1041SU1WW SFP-SX
QXM 0 REV 06 711-028408 ZT9285 MPC QXM
QXM 1 REV 06 711-028408 ZT9232 MPC QXM
ADC 1 REV 02 750-043596 ZW1545 Adapter Card
ADC 2 REV 05 750-043596 CAAC2070 Adapter Card
ADC 13 REV 05 750-043596 CAAC2074 Adapter Card
ADC 14 REV 05 750-043596 ZZ6200 Adapter Card
ADC 16 REV 05 750-043596 CAAC2061 Adapter Card
ADC 17 REV 05 750-043596 CAAC2076 Adapter Card
ADC 18 REV 01 750-043596 ZV4164 Adapter Card
ADC 19 REV 05 750-043596 CAAC2075 Adapter Card
Fan Tray 0 REV 1A 760-042349 VJ00005 Fan Tray
Fan Tray 1 REV 1A 760-042349 VJ00002 Fan Tray
Fan Tray 2 REV 1A 760-042349 VJ00001 Fan Tray
Fan Tray 3 REV 1A 760-042349 VJ00006 Fan Tray
The sample output below shows the DC power chassis hardware:
user@host> show chassis hardware
Hardware inventory:
Item Version Part number Serial number Description
Chassis JN11E336EAFJ MX2020
Midplane REV 29 750-040240 ABAB9382 Lower Power Midplane
Midplane 1 REV 04 711-032386 ABAB9385 Upper Backplane
PMP 1 REV 05 711-032428 ACAJ1526 Upper Power Midplane
PMP 0 REV 04 711-032426 ACAJ1585 Lower Power Midplane
FPM Board REV 06 760-040242 ABBT8836 Front Panel Display
PSM 4 REV 03 740-045050 1EDB23500AF DC 52V Power Supply Module
PSM 5 REV 01 740-045050 1E02224005Z DC 52V Power Supply Module
PSM 6 REV 01 740-045050 1E022240058 DC 52V Power Supply Module
PSM 7 REV 01 740-045050 1E02224005B DC 52V Power Supply Module
PSM 8 REV 01 740-045050 1E02224005A DC 52V Power Supply Module
PSM 13 REV 01 740-045050 1E02224005W DC 52V Power Supply Module
712
