Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2461-901-01 A/November 2015 3-39
Storing configuration index 2
Refer to the instructions in Storing configuration index 1 (on page 3-38), and continue as follows to
configure the instrument for configuration index 2.
Using the front panel to configure the instrument:
Change the following instrument settings to configure the instrument with the settings you want to
save for configuration index 2:
• Set the measure range to 100 mA
• Set NPLC to 2
Using the front panel to store the active settings to configuration index 2:
1. Return to the configuration list menu.
2. Select MyMeasList.
3. Select System to Index. This saves the active system settings to the configuration index.
Select View Details to see some of the settings stored in configuration index 2. See Instrument
settings stored in a measure configuration list (on page 3-33) for information about the settings
that are stored.
4. Select HOME to return to the Home screen.
The procedure above is for a measure configuration list. If you want to create a source configuration
list, under Source, select Config List.
Recalling a configuration index
You can recall the settings stored in a specific configuration index in a configuration list.
For example, use the following procedure to recall configuration index 2 from MyMeasList.
Recall source configuration lists before measure configuration lists. This order ensures that
dependencies between source and measure settings will be properly handled.
Using the front panel to recall a configuration index:
1. Press the MENU key.
2. Under Measure, select Config Lists. The MEASURE CONFIGURATION LISTS screen is
displayed.
If you want to recall an index on a source configuration list, under Source, select Config List.
3. Choose Select List. A menu of available configuration lists is displayed.
4. Select MyMeasList. The configuration indexes in the list display.
5. Select the second configuration index.
6. Select Index to System.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
