Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2461-901-01 A/November 2015 3-59
5. Set the parameters for the sweep command.
6. Set the measurement function using [:SENSe[1]]:FUNCtion.
7. Set the measurement range using [:SENSe[1]]:<function>:RANGe[:UPPer].
8. Make any other settings appropriate to your sweep.
9. Send :INITiate to start the sweep.
To save your settings, save them to a user-saved setup using the *SAV command.
For example sweeps, see Sweep programming examples (on page 3-61).
For detail on the commands and options listed above, see the following command descriptions:
• [:SENSe[1]]:FUNCtion[:ON] (on page 6-81)
• [:SENSe[1]]:<function>:RANGe[:UPPer] (on page 6-65)
• :SOURce[1]:FUNCtion[:MODE] (on page 6-95)
• :SOURce[1]:<function>:RANGe (on page 6-97)
• :SOURce[1]:CONFiguration:LIST:CREate (on page 6-83)
• :SOURce[1]:CONFiguration:LIST:STORe (on page 6-88)
• :SOURce[1]:SWEep:<function>:LINear (on page 6-124)
• :SOURce[1]:SWEep:<function>:LINear:STEP (on page 6-126)
• :SOURce[1]:SWEep:<function>:LIST (on page 6-128)
• :SOURce[1]:SWEep:<function>:LOG (on page 6-130)
Setting up a sweep using TSP commands
To set up a sweep using TSP commands, you send one of the following commands:
• smu.source.sweeplinear(): Sets up a linear sweep for a fixed number of measurement
points.
• smu.source.sweeplinearstep(): Sets up a linear source sweep configuration list and
trigger model with a fixed number of steps.
• smu.source.sweeplist(): Sets up a sweep based on a configuration list, which allows you to
customize the sweep.
• smu.source.sweeplog(): Sets up a logarithmic sweep for a set number of measurement
points.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
