Keithley 2461 Reference Manual

Section
3: Functions and features Model 2461 Interactive SourceMeter® Instrument
Reference Manual
3-132 2461-901-01 A/November 2015
Trigger events – TSP command set
Trigger events
Event description Event constant
No trigger event
trigger.EVENT_NONE
Front-panel TRIGGER key press
trigger.EVENT_DISPLAY
Notify trigger block N (1 to 8) generates a trigger event when
the trigger model executes it
trigger.EVENT_NOTIFYN
A command interface trigger:
• Any remote interface: *TRG
• GPIB only: GET bus command
•
VXI-11: VXI-11 command device_trigger
trigger.EVENT_COMMAND
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line N
(1 to 6)
trigger.EVENT_DIGION
Line edge detected on TSP-Link synchronization line N
(1 to 3)
trigger.EVENT_TSPLINKN
Appropriate LXI trigger packet is received on LAN trigger
object N (1 to 8)
trigger.EVENT_LANN
Trigger event blender N (1 to 2), which combines trigger
events
trigger.EVENT_BLENDERN
Trigger timer N (1 to 4) expired
trigger.EVENT_TIMERN
Source limit condition occurs
trigger.EVENT_SOURCE_LIMIT
Using the TRIGGER key to generate an event
You can use the front-panel TRIGGER key to generate a trigger event.
For example, if you set a wait block to advance when the TRIGGER key is pressed, the trigger model
will reach the wait block. If the TRIGGER key has already been pressed, the trigger model execution
will continue. If the TRIGGER key has not been pressed, the trigger model execution is halted until
the TRIGGER key is pressed.
To set a trigger block to respond to the front-panel key press:
• From the front panel: Set the event to be Display TRIGGER Key
• Using SCPI: Set the event to DISPlay
• Using TSP: Set the event to trigger.EVENT_DISPLAY
There are no action overruns for front-panel TRIGGER key events.
