Keithley 2461

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2461-901-01 A/November 2015 3-141
TRIGger:LOAD:EMPTy
TRIGger:BLOCk:BUFFer:CLE 1, "defbuffer1"
TRIG:BLOC:WAIT 2, DIG5
TRIG:BLOC:SOUR:STAT 3, ON
TRIG:BLOC:DEL:CONS 4, 0.001
TRIG:BLOC:MEAS 5, "defbuffer1"
TRIG:BLOC:SOUR:STAT 6, OFF
TRIG:BLOC:BRAN:LIM:CONS 7, IN, 80, 120, 10, 5
TRIG:BLOC:DIG:IO 8, 15, 15
TRIG:BLOC:BRAN:ALW 9, 20
TRIG:BLOC:BRAN:LIM:CONS 10, IN, 90, 110, 13, 5
TRIG:BLOC:DIG:IO 11, 1, 15
TRIG:BLOC:BRAN:ALW 12, 20
TRIG:BLOC:BRAN:LIM:CONS 13, IN, 95, 105, 16, 5
TRIG:BLOC:DIG:IO 14, 2, 15
TRIG:BLOC:BRAN:ALW 15, 20
TRIG:BLOC:BRAN:LIM:CONS 16, IN, 99, 101, 19, 5
TRIG:BLOC:DIG:IO 17, 3, 15
TRIG:BLOC:BRAN:ALW 18, 20
TRIG:BLOC:DIG:IO 19, 4, 15
TRIG:BLOC:DEL:CONS 20, 0.001
TRIG:BLOC:DIG:IO 21, 0, 15
TRIG:BLOC:NOT 22, 1
TRIG:BLOC:BRAN:COUN 23, 10, 2
Clear any existing trigger model commands
from the instrument.
Set up the trigger model:
• Block 1: Clear default buffer 1.
• Block 2: Set up a wait block to wait for
digital line 5.
• Block 3: Turn the source output on.
• Bock 4: Set a constant delay of .001
s.
• Block 5: Make a measurement and
store it in default buffer 1.
• Block 6: Turn the output off.
• Block 7: Set up the constant limits to
perform the first test.
• Block 8: If block 7 fails, drive the
digital I/O lines high.
• Blocks 9, 12, 15, and 18: Branch to
block 20.
• Block 10: Set up the constant limits to
perform the second test.
• Block 11: If block 10 fails, drive line 1
high.
• Block 13: Set up the constant limits to
perform the third test.
• Block 14: If block 13 fails, drive line 2
high.
• Block 16: Set up the constant limits to
perform the fourth test.
• Block 17: If block 10 fails, drive lines 1
and 2 high.
• Block 19: If block 10 fails, drive line 3
high.
• Block 20: Delay for 1 ms
• Block 21: Set all digital lines low.
• Block 22: Send out a notify event to
indicate that the test has ended.
•
Block 23: Return to block 2 23 times.
