Keithley 2461 Reference Manual

Section
3: Functions and features Model 2461 Interactive SourceMeter® Instrument
Reference Manual
3-160 2461-901-01 A/November 2015
TSP-Link commands
Command Description
trigger.tsplinkin[N].clear() (on page 8-310)
Clears the event detector for a trigger
trigger.tsplinkin[N].edge (on page 8-311)
Indicates which trigger edge controls the trigger
event detector for a trigger line
trigger.tsplinkin[N].overrun (on page 8-311)
Indicates if the event detector ignored an event
while in the detected state
trigger.tsplinkin[N].wait() (on page 8-312) Waits for a trigger
trigger.tsplinkout[N].assert() (on page 8-313)
Simulates the occurrence of the trigger and
generates the corresponding trigger event
trigger.tsplinkout[N].logic (on page 8-313) Defines the trigger output with output logic for a
trigger line
trigger.tsplinkout[N].pulsewidth (on page 8-
314)
Sets the length of time that the trigger line is
asserted for output triggers
trigger.tsplinkout[N].release() (on page 8-315)
Releases a latched trigger on the given TSP-Link
trigger line
trigger.tsplinkout[N].stimulus (on page 8-315)
Specifies the event that causes the
synchronization line to assert a trigger
tsplink.group (on page 8-317)
The group number of the TSP-Link node
tsplink.initialize() (on page 8-318)
Initializes all instruments and enclosures in the
TSP-Link system
tsplink.line[N].mode (on page 8-319)
Defines the trigger operation of a TSP-Link line
as digital in or out or trigger in or out
tsplink.line[N].reset() (on page 8-320)
Resets some of the TSP-Link trigger attributes to
their defaults
tsplink.line[N].state (on page 8-320) Reads or writes the digital state of a TSP-Link
synchronization line
tsplink.master (on page 8-321)
Reads the node number assigned to the master
node
tsplink.node (on page 8-322) Defines the node number
tsplink.readport() (on page 8-322)
Reads the TSP-Link synchronization lines as a
digital I/O port
tsplink.state (on page 8-323)
Describes the TSP-Link online state
tsplink.writeport() (on page 8-323)
Writes to all TSP-Link synchronization lines as a
digital I/O port

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
