Keithley 2461 Reference Manual

Section
4: Source-measure considerations Model 2461 Interactive SourceMeter® Instrument
Reference Manual
4-32 2461-901-01 A/November 2015
Not available from front panel
:TRIGger:TIMer<n>:STARt:FRACtional (on page 6-238)
trigger.timer[N].start.fractionalseconds (on page 8-306)
0
Not available from front panel
:TRIGger:TIMer<n>:STARt:GENerate (on page 6-239)
trigger.timer[N].start.generate (on page 8-306)
Off
Not available from front panel
:TRIGger:TIMer<n>:STARt:SEConds (on page 6-240)
trigger.timer[N].start.seconds (on page 8-308)
0
Not available from front panel
:TRIGger:TIMer<n>:STARt:STIMulus (on page 6-241)
trigger.timer[N].start.stimulus (on page 8-308)
No event
Not available from front panel
:TRIGger:TIMer<n>:STATe (on page 6-242)
trigger.timer[N].enable (on page 8-304)
Off
Not available from front panel
Not applicable for SCPI
trigger.tsplinkin[N].edge (on page 8-311)
Falling
Not available from front panel
Not applicable for SCPI
trigger.tsplinkout[N].logic (on page 8-313)
Negative
Not available from front panel
Not applicable for SCPI
trigger.tsplinkout[N].pulsewidth (on page 8-314)
10e-6 s
TSP-Link and TSP-Net reset values
Setting Default value on
reset
Not available from front panel
Not applicable for SCPI
tsplink.line[N].mode (on page 8-319)
Digital open drain
Not available from front panel
Not applicable for SCPI
tspnet.timeout (on page 8-332)
20
Not available from front panel
Not applicable for SCPI
tspnet.tsp.abortonconnect (on page 8-333)
1

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
