Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 4: Source-
measure considerations
2461-901-01 A/November 2015 4-31
Trigger reset values
Setting Default value on
reset
Not available from front panel
:TRIGger:BLENder<n>:MODE (on page 6-183)
trigger.blender[N].orenable (on page 8-236)
AND
Not available from front panel
:TRIGger:DIGital<n>:IN:EDGE (on page 6-211)
trigger.digin[N].edge (on page 8-242)
Falling edge
Not available from front panel
:TRIGger:DIGital<n>:OUT:LOGic (on page 6-213)
trigger.digout[N].logic (on page 8-245)
Negative
Not available from front panel
:TRIGger:DIGital<n>:OUT:PULSewidth (on page 6-214)
trigger.digout[N].pulsewidth (on page 8-245)
10e-6 s
Not available from front panel
:TRIGger:DIGital<n>:OUT:STIMulus (on page 6-214)
trigger.digout[N].stimulus (on page 8-247)
None
Not available from front panel
:TRIGger:LAN<n>:IN:EDGE (on page 6-216)
trigger.lanin[N].edge (on page 8-249)
Either edge
Not available from front panel
:TRIGger:LAN<n>:OUT:IP:ADDRess (on page 6-218)
trigger.lanout[N].ipaddress (on page 8-254)
0.0.0.0
Not available from front panel
:TRIGger:LAN<n>:OUT:PROTocol (on page 6-220)
trigger.lanout[N].protocol (on page 8-255)
TCP
Not available from front panel
:TRIGger:LAN<n>:OUT:STIMulus (on page 6-220)
trigger.lanout[N].stimulus (on page 8-256)
None
Not available from front panel
:TRIGger:TIMer<n>:COUNt (on page 6-236)
trigger.timer[N].count (on page 8-301)
1
Not available from front panel
:TRIGger:TIMer<n>:DELay (on page 6-238)
trigger.timer[N].delay (on page 8-303)
10e-6 s

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
