Keithley 2461 Reference Manual

Section
8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
8-60 2461-901-01 A/November 2015
Example
optionID = display.input.option("Select an option", "Apple", "Orange", "Papaya",
"Pineapple", "Blueberry", "Banana", "Grapes", "Peach", "Apricot", "Guava")
print(optionID)
This example displays the following dialog box:
If the user selects
Peach
, the return is
display.BUTTON_OPTION8
.
Also see
display.input.number() (on page 8-57)
display.input.prompt() (on page 8-61)
display.input.string() (on page 8-62)

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
