Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 245
Measurement Illustration
Distance
Determines the direct, Euclidean distance between two
feature points.
Center X
Finds the average location of two features and measures
the X axis position of the average location
Center Z
Finds the average location of two features and measures
the Z axis position of the average location.
Parameter Description
Source The sensor, or combination of sensors, that provides data
for the tool's measurements. For more information, see
Source on page 201.
Stream The data that the tool will apply measurements to.
In Surface mode, this setting is only displayed when a
section is defined on the surface data.
For more information on sections, see Sections on page 190.
Parameters
