Gocator Line Profile Sensors: User Manual
Gocator Device Files • 496
Element Type Description
IncludeSinglePointsEnabled Bool Enables preservation of single data points in Top+Bottom layout
IncludeSinglePointsEnabled.
used
Bool Whether or nto this field is available to be modified
EdgeFiltering Section
See EdgeFiltering below.
EdgeFiltering
Element Type Description
@used Bool Whether or not this section is used.
Enabled Bool Enables edge filtering.
PreserveInteriorEnabled Bool Enables preservation of interior.
ElementWidth 64f Element width (mm).
ElementWidth.min 64f Minimum element width (mm).
ElementWidth.max 64f Maximum element width (mm).
ElementLength 64f Element length (mm).
ElementLength.min 64f Minimum element length (mm).
ElementLength.max 64f Maximum element length (mm).
EdgeFiltering Child Elements
PartMatching
The PartMatching element contains settings related to part matching.
Element Type Description
Enabled Bool Enables part matching.
Enabled.used Bool Whether or not this field is used.
MatchAlgo 32s
Match algorithm.
0 – Edge points
1 – Bounding Box
2 – Ellipse
Edge Section
See Edge below.
BoundingBox Section
See BoundingBox on the next page.
Ellipse Section
See Ellipse on the next page.
PartMatching Child Elements
Edge
Element Type Description
ModelName String Name of the part model to use. Does not include the .mdl extension.
Acceptance/Quality/Min 64f Minimum quality value for a match.
Edge Child Elements
