Gocator Line Profile Sensors: User Manual
Gocator Device Files • 477
Element Type Description
donly
UniformSpacingEnabled.valu
e
Bool Actual value used if not configurable.
IntensityEnabled Bool Enables intensity data collection.
IntensityEnabled.used Bool Whether or not property is used.
IntensityEnabled.value Bool Actual value used if not configurable.
FlickerFreeModeEnabled Bool Enables flicker-free operation.
FlickerFreeModeEnabled.use
d
Bool Whether flicker-free operation can be used on this sensor.
ExternalInputZPulseEnabled Bool Enables the External Input based encoder Z Pulse feature.
ExternalInputZPulseIndex 32u Input index to use for the input triggered z pulse feature.
ExternalInputZPulseEnabled.
used
Bool Whether the index can be set.
BackgroundSuppression Section
See BackgroundSuppression below.
Filters Section
See Filters below.
Trigger Section
See Trigger on page 480.
Layout Section
See Layout on page 482.
Alignment Section
See Alignment on page 483.
Devices Collection A collection of two Device sections (with roles main and buddy). See
Devices / Device on page 485.
SurfaceGeneration Section
See SurfaceGeneration on page 491.
SurfaceSections Section See
SurfaceSections on page 492
.
ProfileGeneration Section
See ProfileGeneration on page 493. Used by Gocator displacement
sensors.
PartDetection Section
See PartDetection on page 494.
PartMatching Section
See PartMatching on page 496.
Custom Custom Used by specialized sensors.
BackgroundSuppression
The BackgroundSuppression element contains settings related to background suppression.
Element Type Description
Enabled Bool Enables background suppression.
FrameRatio 64f Ratio of background frames to calibration frames
BackgroundSuppression Child Elements
Filters
The Filters element contains settings related to post-processing profiles before they are output or used
by measurement tools.
