Gocator Line Profile Sensors: User Manual
Gocator Device Files • 530
Element Type Description
1 – GDK user-defined tool
2 – Internal GDK tool
@id
32s The tool's ID.
Name String Tool name.
Code String Script code.
Measurements\Output (Collection) Dynamic list of Output elements.
Element Type Description
@id 32s
Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Output
SurfaceBoundingBox
A SurfaceBoundingBoxelement defines settings for a surface bounding box tool and one or more of its
measurements.
Element Type Description
@isCustom Bool Reserved for future use.
@format 32s
Format type of the tool:
0 – Standard built-in tool
1 – GDK user-defined tool
2 – Internal GDK tool
@id
32s The tool's ID.
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See SurfaceBoundingBox above.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions elements.
Stream\Step
32s The stream source step. Possible values are:
SurfaceBoundingBoxChild Elements
