LMI Technologies Gocator 2100 Series - Measurements, Features, and Settings

Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 256
Measurements, Features, and Settings
Measurement Illustration
StandardDeviation
Finds the best-fitted line and measures the standard
deviation of the data points from the line.
Min Error
Finds the best-fitted line and measures the minimum error
from the line (the maximum distance below the line).
Max Error
Finds the best-fitted line and measures the maximum error
from the line (the maximum distance above the line).
Percentile
Finds the best-fitted line and measures the range (in Z) that
covers a percentage of points around the line.
Offset
Finds the best-fitted line and returns the intersection point
between that line and the Z axis.
Angle
Finds the best-fitted line and returns the angle relative to
the X axis.
Min Error X
Min Error Z
Finds the best-fitted line and returns the X or Z position of
the minimum error from the line (the maximum distance
below the line).
Measurements
