Gocator Line Profile Sensors: User Manual
Tools and Native Drivers • 713
Field Description
(x values)
Each column in header is a resampled X position
Each column in data is the range (mm) or intensity (count)
RawProfile
This section describes point cloud profile data (or unresampled / raw data),which is produced when the
sensor is in Profile mode and uniform spacing is disabled. It has two sub-sections: attributes and data.
The attribute section has only one row of data.
Field Description
Frame Count Total number of frames
Column Count Number of columns
X Offset X offset (mm)
Y Offset Y offset (mm)
Z Offset Z offset (mm)
Attribute Section Fields
The data section has one or more rows of data per frame (for example, range and intensity).
Field Description
Frame Frame index
Source Source (for example, 0 for Top)
Time Stamp time
Encoder Stamp encoder
Z Encoder Stamp encoder Z
Inputs Stamp inputs
Exposure Stamp exposure (µs)
Y Y value (mm)
Axis Axis: X, Z, or I (Intensity)
(x values)
Each column in header is an index.
Each column in data is the X/Z value (mm) or intensity (count)
Data Section Fields
Part
This section describes uniform (or resampled) surface data, which is produced when the sensor is in
Surface mode and uniform spacing is enabled.
Only the data for the frame currently selected in the UIis exported when you export part data to
a CSVfile.
The section has two sub-sections: attributes and data.
The attribute section has only one row of data.
