Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 322
Measurement Panel
For information on adding, managing, and removing tools and measurements, as well as detailed
descriptions of settings common to most tools, see Tools Panel on page 198.
Measurements, Data, and Settings
Measurement
Global Max
Global Min
Global Flatness
The maximum distance, minimum distance, and flatness (maximum - minimum) calculated using the valid data from all
the cells in the grid (when Region Mode is set to Grid Pattern), or all the individual regions (when Region Mode is set to
Flexible).
Measurements
