Gocator Line Profile Sensors: User Manual
Gocator Device Files • 492
FixedLength
Element Type Description
StartTrigger 32s
Start trigger condition:
0 – Sequential
1 – Digital input
ExternalInputIndex 32s
Index of external input when trigger source is set to 1 – Digital Input and
connected to a Master.
0 – first digital input
1 – second digital input
2 – third digital input
3 – fourth digital input
ExternalInputIndex.options 32s (CSV) List of available external input indices.
ExternalInputIndex.used Bool Is the external input index in use.
Length 64f
Surface length (mm).
Length.min 64f
Minimum surface length (mm).
Length.max 64f
Maximum surface length (mm).
FixedLength Child Elements
VariableLength
Element Type Description
MaxLength 64f Maximum surface length (mm).
MaxLength.min 64f
Minimum value for maximum surface length (mm).
MaxLength.max 64f
Maximum value for maximum surface length (mm).
VariableLength Child Elements
Rotational
Element Type Description
Circumference 64f Circumference (mm).
Circumference.min 64f Minimum circumference (mm).
Circumference.max 64f Maximum circumference (mm).
Rotational Child Elements
SurfaceSections
Element Type Description
@used Bool Whether surface sectioning is enabled.
@xMin 64f The minimum valid X value to be used for section definition.
@xMax 64f The maximum valid X value to be used for section definition.
SurfaceSections Child Elements
