Gocator Line Profile Sensors: User Manual
Gocator Device Files • 480
Element Type Description
@used Bool Whether or not this field is used
Enabled Bool Enables filtering.
Window 64f Window size (mm).
Window.min 64f Minimum window size (mm).
Window.max 64f Maximum window size (mm).
XSlope Child Elements
YSlope
This filter is only available on displacement sensors.
Element Type Description
@used Bool Whether or not this field is used
Enabled Bool Enables filtering.
Window 64f Window size (mm).
Window.min 64f Minimum window size (mm).
Window.max 64f Maximum window size (mm).
YSlope Child Elements
Trigger
The Trigger element contains settings related to trigger source, speed, and encoder resolution.
Element Type Description
Source 32s
Trigger source:
0 – Time
1 – Encoder
2 – Digital Input
3 – Software
Source.options 32s (CSV) List of available source options.
ExternalInputIndex 32s
Index of external input when Source is set to 2 – Digital Input and
connected to a Master.
0 – first digital input
1 – second digital input
2 – third digital input
3 – fourth digital input
ExternalInputIndex.options 32s (CSV) List of available external input indices.
ExternalInputIndex.used Bool Whether the external input index used.
Units 32s
Sensor triggering units when source is not clock or encoder:
0 – Time
Trigger Child Elements
