Protocols • 640
and the sample state assembly object (380 bytes). The data attribute (0x03) of the assembly objects is a
byte array containing information about the sensor. The data attribute can be accessed with the Get
Attribute and Set Attribute commands.
The PLC sends a command to start a Gocator. The PLC then periodically queries the attributes of the
assembly objects for its latest measurement results. In EtherNet/IP terminology, the PLC is a scanner
and the Gocator is an adapter.
For detailed information on setting up explicit messaging using Allen-Bradley PLCs, see
https://downloads.lmi3d.com/setting-ethernetip-explicit-messaging-allen-bradley-plcs.
The following sections describe the explicit messaging assemblies and objects.
Identity Object (Class 0x01)
Attribute Name Type Value Description Access
1 Vendor ID UINT 1256 ODVA-provided vendor ID Get
2 Device Type UINT 43 Device type Get
3 Product Code UINT 1 Product code Get
4 Revision USINT 1.1 Byte 0 - 1
Byte 1 - 1
Get
6 Serial number UDINT 32-bit value Sensor serial number Get
7 Product
Name
SHORT
STRING
32
"Gocator" Gocator product name Get
TCP/IP Object (Class 0xF5)
The TCP/IP Object contains read-only network configuration attributes such as IP Address.TCP/IP
configuration via Ethernet/IP is not supported. See Volume 2, Chapter 5-3 of the CIP Specification for a
complete listing of TCP/IP object attributes.
Attribute Name Type Value Description Access
1 Status UDINT 0 TCP interface status Get
2 Configuration
Capability
UINT 0 Get
3 Configuration
Control
UINT 0 Product code Get
4 Physical Link
Object
Structure (See
description)
See 5.3.3.2.4 of CIP Specification Volume 2:
Path size (UINT)
Path (Padded EPATH)
Get
5 Interface
Configuration
Structure (See
description)
See 5.3.3.2.5 of CIP Specification Volume 2:
IP address (UDINT)
Network mask (UDINT)
Gateway address (UDINT)
Get
