Gocator Line Profile Sensors: User Manual
Gocator Device Files • 557
Parameters\HeightAbsolute
(Height measurement only)
GdkParamBool Absolute height enabled boolean.
Tool (type FeatureIntersect)
A Tool element of type FeatureIntersect defines settings for a feature intersection tool and one or more
of its measurements.
Element Type Description
@isCustom Bool Reserved for future use.
@format 32s
Format type of the tool:
0 – Standard built-in tool
1 – GDK user-defined tool
2 – Internal GDK tool
@id
32s The tool's ID.
@type String Type name of the tool.
@version String Version string for custom tool.
Name String Tool name.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Parameters\Line
GdkParamGeometricFeature
Line feature input.
Parameters\RefLine GdkParamGeometricFeature Reference line feature input.
Measurements\Measurement
@type=\X
Intersect Measurement
X measurement.
Measurements\Measurement
@type=Y
Intersect Measurement Y measurement.
Measurements\Measurement
@type=Z
Intersect Measurement Z measurement.
Measurements\Measurement
@type=Angle
Intersect Measurement Angle measurement.
Features\IntersectPoint
GDKFeature
Intersect point feature.
Tool Child Elements
@id 32s
Measurement ID. Optional (measurement disabled if not
set).
Intersect Measurement Child Elements
