Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 394
Original data with overlay
Transformed data
The direction of the X axis depends on the tool generating the line that Surface Transform takes as input.
You may need to adjust the direction using the Add Fixed Transform settings.
Point
New Z=0 XY Plane New X Axis New Origin
Through the input point, parallel to old Z=0 plane. Parallel to the old axis. The input point.
