Gocator Line Profile Sensors: User Manual
Specifications • 767
Power
Apply positive voltage to DC_24-48V. See Gocator 2100 & 2300 Series on page 720 or Gocator 2400 Series
on page 743
Function Pins Min Max
DC_24-48V A 24 V 48 V
GND_24-48VDC L 0 V 0 V
Power requirements
Laser Safety Input
The Safety_in+ signal should be connected to a voltage source in the range listed below. The Safety_in-
signal should be connected to the ground/common of the source supplying the Safety_in+.
Function Pins Min Max
Safety_in+ J 24 V 48 V
Safety_in- G 0 V 0 V
Laser safety requirements
Confirm the wiring of Safety_in- before starting the sensor. Wiring DC_24-48V into Safety_in- may
damage the sensor.
