Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 403
Data and Settings
Type Description
Corrected Surface Surface data corrected for vibration, available for use as
input in the Stream drop-down in other tools.
Difference Surface
Diagnostic Surface data showing the difference
between the corrected surface and the original.
Available for use as input in the Stream drop-down in
other tools
Data
Parameter Description
Source The sensor, or combination of sensors, that provides data
for the tool's measurements. For more information, see
Source on page 201.
Correct region only If enabled, only the area under the region is corrected for
vibration in the output surface data. This setting can be
useful if vibration regularly occurs in a specific area of the
scan data.
This option is only displayed if Use Region is enabled.
Use Region When enabled, lets you set a region and optionally choose
to apply vibration correction only to that region (using
Correct region only).
Region The region whose data the tool will use to calculate the
vibration correction.
Parameters
Anchor Description
X, Y, or Z Lets you choose the X, Y, or Z measurement of another tool
to use as a positional anchor for this tool.
Z angle Lets you choose the Z Angle measurement of another tool to
use as an angle anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 211.
