LMI Technologies Gocator 2100 Series User Manual

Gocator Line Profile Sensors: User Manual
Gocator Device Files • 531
Element Type Description
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
ZRotationEnabled Boolean Setting to enable/disable rotation of bounding box
AsymmetryDetectionType 32s
Determine whether to use asymmetry detection and if
enabled, which dimension would be the basis of detection.
The possible values are:
0 – None
1 – Length
2 – Width
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
Measurements\X Bounding Box tool
measurement
X measurement.
Measurements\Y Bounding Box tool
measurement
Y measurement.
Measurements\Z Bounding Box tool
measurement
Z measurement.
Measurements\Width Bounding Box tool
measurement
Width measurement.
Measurements\Length BoundingBoxMeasure
ment
Length measurement
Measurements\Height Bounding Box tool
measurement
Height measurement.
Measurements\ZAngle Bounding Box tool
measurement
ZAngle measurement.
Measurements\GlobalX Bounding Box tool
measurement
Global X measurement.
Measurements\GlobalY Bounding Box tool
measurement
Global Y measurement.
Measurements\GlobalZAngle Bounding Box tool
measurement
Global Z Angle measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
Features\AxisLine
GeometricFeature
AxisLine LineFeature
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
Bounding Box Tool Measurement
