Parameter Description
FittingRegions Determines which data Gocator uses to fit the line over the
profile.
When Fitting Regions is enabled, Gocator uses the data
indicated by one of the following options:
l All Data: All of the data in the profile is used to fit the
line.
l 1 Region:Data from a fitting region you define in the
data viewer is used to fit the line.
l 2 Regions:Data from two fitting regions you define is
used to fit the line.
When Fitting Regions is disabled, to fit the line, Gocator
uses the measurement region if Region is enabled, or the
entire profile if Region is disabled.
When Fitting Regions is enabled and 1 Region or 2 Regions
is selected, you can set the region (or regions) graphically in
the data viewer, or you can expand the feature using the
expand button ( ) and enter the values in the fields. For
more information on regions, see Regions on page 201.
Percent
(Percentile measurement only)
The specified percentage of points around the best-fitted
line.
Filters The filters that are applied to measurement values before
they are output. For more information, see Filters on page
209.
Decision The Max and Min settings define the range that determines
whether the measurement tool sends a pass or fail decision
to the output. For more information, see Decisions on page
208.
Anchor Description
X or Z Lets you choose the X or Z measurement of another tool to
use as a positional anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 211.
