Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 296
Measurement Illustration
Distance
Determines the direct, Euclidean distance between the
selected features.
Plane Distance
Determines the distance between the selected features.
The position of the lowest feature point is projected onto
the XY plane of the highest feature point.
Center X
Determines the X position of the center point between the
selected features.
Center Y
Determines the Y position of the center point between the
selected features.
Center Z
Determines the Z position of the center point between the
selected features.
Parameter Description
Source The sensor, or combination of sensors, that provides data
for the tool's measurements. For more information, see
Source on page 201.
Parameters
