Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 416
Measurement Illustration
X, Y, Z
The X, Y, and Zpositions of some aspect of the geometric
feature. For more information, see the sections above.
XAngle, YAngle, ZAngle
The X, Y, and Zangles of some aspect of the geometric
feature. For more information, see the sections above.
Measurements
Note that even when enabled on the Features tab, not all features are generated. (For example, with
Line selected as the output type, only a line geometric feature can be generated:point, circle, and plane
features are not generated.)
Type Description
Point The generated point geometric feature.
Line The generated line geometric feature.
Circle The generated circle geometric feature.
Plane The generated plane geometric feature.
Features
Parameter Description
Output The type of output the tool generates. Switching between
the options changes the input types displayed in the tool.
Show Detail Toggles the display of the input geometric features in the
data viewer.
Filters The filters that are applied to measurement values before
they are output. For more information, see Filters on page
209.
Decision The Max and Min settings define the range that determines
whether the measurement tool sends a pass or fail decision
to the output. For more information, see Decisions on page
208.
Parameters
