Gocator Line Profile Sensors: User Manual
Gocator Device Files • 516
Element Type Description
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
Shape 32s
Shape:
0 – U-shape
1 – V-shape
2 – Open
MinDepth 64f Minimum depth.
MinWidth 64f Minimum width.
MaxWidth 64f Maximum width.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Measurement region.
Measurements\X Groove tool
measurement
X measurement.
Measurements\Z Groove tool
measurement
Z measurement.
Measurements\Width Groove tool
measurement
Width measurement.
Measurements\Depth Groove tool
measurement
Depth measurement.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
Groove Tool Measurement
