Gocator Line Profile Sensors: User Manual
Gocator Device Files • 520
Element Type Description
Region
ProfileRegion2d
Measurement region.
FittingRegions
ProfileLine
ProfileLine describing up to 2 regions to fit to.
FittingRegionsEnabled Bool Whether the fitting regions are enabled.
Measurements\StdDev Line tool
measurement
StdDev measurement.
Measurements\MaxError Line tool
measurement
MaxError measurement.
Measurements\MinError Line tool
measurement
MinError measurement.
Measurements\Percentile Line tool
measurement
Percentile measurement.
Measurements\Offset Line tool
measurement
Offset measurement.
Measurements\Angle Line tool
measurement
Angle measurement.
Measurements\MinErrorX Line tool
measurement
Minimum Error in Z measurement.
Measurements\MinErrorZ Line tool
measurement
Minimum Error in Z measurement.
Measurements\MaxErrorX Line tool
measurement
Maximum Error in X measurement.
Measurements\MaxErrorZ Line tool
measurement
Maximum Error in Z measurement.
Features\Line
GeometricFeature
Line LineFeature.
Features\ErrorMinPoint GeometricFeature ErrorMinPoint PointFeature.
Features\ErrorMaxPoint GeometricFeature ErrorMaxPoint PointFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
Line Tool Measurement
