Gocator Line Profile Sensors: User Manual
Gocator Device Files • 536
Element Type Description
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Anchor\ZAngle String (CSV) The Z Angle measurements (IDs) used for anchoring.
Anchor\ZAngle.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
Measurements\CenterX Dimension tool
measurement
Center X measurement
Measurements\CenterY Dimension tool
measurement
Center Y measurement
Measurements\CenterZ Dimension tool
measurement
Center Z measurement
Measurements\Distance Dimension tool
measurement
Distance measurement
Measurements\PlaneDistance Dimension tool
measurement
Plane Distance measurement
Measurements\Height Dimension tool
measurement
Height measurement
Measurements\Length Dimension tool
measurement
Length measurement
Measurements\Width Dimension tool
measurement
Width measurement
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
Dimension Tool Measurement
