Gocator Line Profile Sensors: User Manual
Gocator Device Files • 543
Element Type Description
4 – Section
Stream\Id 32u The stream source ID.
NominalRadius 64f Nominal radius (mm).
RadiusTolerance 64f Radius tolerance (mm).
PartialDetectionEnabled Boolean
Setting to enable/disable partial detection:
0 – Disable
1 – Enable
DepthLimitEnabled Boolean Setting to enable/disable depth limit:
0 – Disable
1 – Enable
DepthLimit 64f The depth limit relative to the surface. Data below this limit
is ignored.
RegionEnabled Boolean
Setting to enable/disable region:
0 – Disable
1 – Enable
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
1 – Enable
RefRegionCount 32s
Count of the reference regions that are to be used.
(Advanced tab.)
RefRegions (Collection) Reference regions. Contains up to two RefRegion elements
of type SurfaceRegion2D. (Advanced tab.)
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction:
0 – Auto Set
1 – Custom
TiltXAngle 64f Setting for custom tilt correction angle X.
TiltYAngle 64f Setting for custom tilt correction angle Y.
Measurements\X Hole tool
measurement
X measurement.
Measurements\Y Hole tool
measurement
Y measurement.
Measurements\Z Hole tool
measurement
Z measurement.
Measurements\Radius Hole tool
measurement
Radius measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
