Gocator Line Profile Sensors: User Manual
Gocator Device Files • 546
Element Type Description
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions (Advanced tab):
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions that are to be used.
(
Advanced
tab.)
RefRegions
(Collection) Reference regions. Contains two RefRegion elements of type
SurfaceRegion2D.
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction (Advanced tab):
0 – Disable
1 – Enable
TiltXAngle 64f Setting for custom tilt correction angle X.
TiltYAngle 64f Setting for custom tilt correction angle Y.
Measurements\X Opening tool
measurement
X measurement.
Measurements\Y Opening tool
measurement
Y measurement.
Measurements\Z Opening tool
measurement
Z measurement.
Measurements\Width Opening tool
measurement
Width measurement.
Measurements\Length Opening tool
measurement
Length measurement.
Measurements\Angle Opening tool
measurement
Angle measurement.
Features\CenterPoint
GeometricFeature
CenterPoint PointFeature
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
Opening Tool Measurement
