OPERATION
2. Disconnect electrical harness at connector (B) from
windrower and store harness (A) on weight box.
Figure 4.49: Electrical Harness
3. Disconnect electrical harness (A) from windrower, and
store harness on tow-bar.
Figure 4.50: Electrical Connector
4. Undo lock (A), remove safety chain (B) from drawbar,
and remove clevis pin (C).
Figure 4.51: Drawbar Hitch
169890
1
12
Revision A
