MAINTENANCE AND SERVICING
6. Oil level should be between LOW and HIGH. If level is
below LOW mark , 2 US quarts (1.9 liters) will raise the
level from LOW to HIGH.
NOTE:
Ifyouneedtoaddoil,refertoAdding Engine Oil, page
229.
7. Replace dips
tick and turn it clockwise to lock.
8. Close the hoo
d. Refer to 5.4.4 Closing Hood (Highest
Position), p
age 204.
Figure 5.61: Engine Oil Level
Changing Engine Oil
Refer to th
e following procedures:
• Checking E
ngine Oil Level, page 227
• Draining
Engine Oil, page 228
• Replacin
g Engine Oil Filter, page 229
• Adding En
gine Oil, page 229
Drainin
g Engine Oil
DANGER
Stop engine and remove key from ignition before leaving operator's seat for any reason. A child or even a
pet could engage an idling machine.
NOTE:
The engine should be warm prior to changing the oil.
1. Stop the engine and remove the key.
2. Place a drain pan with a capacity of about 6 US ga llo ns
(24 liters) under the engine oil drain.
169890 228 Revision A
