MAINTENANCE AN D SERVICING
Servicing Drive Wheel
To service a drive wheel, refer to the following procedures:
• Ra isin g Drive Whee l, page 303
• Removing Drive Wheel, page 304
• In sta lling Drive Wheel, page 304
• Lowering Drive Wheel, page 305
Raising Drive Wheel
This proced
ure can be used on both drive wheels.
CAUTION
Header MUST be removed and NO weight box installed. Use a hydraulic jack w ith minimum lifting capacity
of 5000 lb (2268 kg) to provide adequate support for the machine.
1. Remove the header.
2. Park windrower on level ground and block all wheels.
DANGER
Stop engine and rem
ove key from ignition before
leaving operator'
s seat for any reason. A child or
even a pet could en g
age an idling machine.
3. Place ground speed lever (GSL [A]) in N-DETENT (B),
shut down engine, and remove key.
Figure 5.197: Ground Speed Lever
CAUTION
Jack stand must be capable of supporting a minimum
of 5000 lb (2268 kg).
4. Place a jack under the leg jack point (A) and raise the
drive wheel until it is slightly off ground. Place a jack
stand beneath the lift cylinder mount (B).
NOTE:
Do NOT place jack stand under the cylinder. Use a small
metal plate on top of the jack stand.
5. Lower the win
drower onto the ja c k s tand.
Figure 5.198: Drive Wheel Jack Point
169890 303 Revision A
