Proceed as follows:
On the right-hand side of the
printing system:
To swivel off the toner mark
sensor, pull the unit outwards by
the handle.
7.
Open the handles on the locking
flaps.
8.
Fold up the locking flaps.
The locking flaps automatically
lock into position when they
have been folded up far enough.
9.
Chapter 9 - Replacing Expendables354
Removing Photoconductor Belt in Upper Print Unit and Replacing Photoconductor Blade
