Proceed as follows:
Push the sliding foil in until the
edge of the transfer belt is posi-
tioned between the four emboss-
ing marks.
The distance between the inser-
tion tool and the green tube
must not be greater than 5 cm
(2").
11.
Close the insertion tool, thereby lowering it to the transfer belt.12.
Chapter 9 - Replacing Expendables 389
Insert the Transfer Belt in the Upper Print Unit
