Proceed as follows:
Holding the insertion tool with
your left hand and the lower
sliding foil with your right hand,
evenly and carefully push the
transfer belt onto the transfer
unit until the control LED turns
green.
13.
Remove all three tubes from the transfer unit and place them in the original
packaging.
14.
Note
Keep the tubes. You can use them to insert a used but undamaged transfer
belt at a later date, if necessary.
Hold the insertion tool with
both hands and carefully move
it in the direction of the arrow
up to the mark (white arrow).
The control LED must turn
green.
15.
Chapter 9 - Replacing Expendables390
Insert the Transfer Belt in the Upper Print Unit
