Proceed as follows:
Fold locking flap upwards.
The locking flap locks into posi-
tion automatically when it has
been folded up far enough.
7.
Turn rotating handle 180° in the
direction of the arrow to the stop
point to slacken the transfer belt.
8.
#
‘Removing the Transfer Belt in the Lower Print Unit ’ on page 398.9.
Chapter 9 - Replacing Expendables 397
Removing the Transfer Belt in the Lower Print Unit - Preparation
