Proceed as follows:
■
If the upper smoothing roller
is to be replaced:
Pull the slide-in unit for the
upper cleaning felt (A)
halfway out by the handle,
until it snaps in.
■
If the lower smoothing roller
is also (or only) to be re-
placed:
Pull the slide-in unit for the
lower cleaning felt (B)
halfway out by the handle,
until it snaps in.
A
B
5.
On the left-hand side of the
printing system:
Open paper cooling cover.
6.
Caution
Beware of the edges of the open blower unit.
Open the blower unit fully and beware of the edges of the blower unit during
the following actions.
Chapter 9 - Replacing Expendables456
Removing the smoothing rollers
