Proceed as follows:
Remove the lower smoothing
roller:
■
Open the locking mechanism
on the left-hand side (in pa-
per path direction) and push
the bearing bolts downwards.
■
Open the locking mechanism
on the right-hand side (in
paper path direction) and
push the bearing bolts down-
wards.
■
Carefully remove the
smoothing roller from the
guide rails
1
2
3
16.
‘Installing smoothing rollers’ on page 461.17.
Chapter 9 - Replacing Expendables460
Removing the smoothing rollers
