Proceed as follows:
On the right-hand side of the
printing system:
■
If the upper smoothing roller
is to be replaced:
Push the slide-in unit for the
upper cleaning felt (A) by the
handle until it snaps into
place in the smoothing mod-
ule.
■
If the lower smoothing roller
is also (or only) to be re-
placed:
Push the slide-in unit for the
lower cleaning felt (B) by the
handle until it snaps into
place in the smoothing mod-
ule.
11.
Unlock the sliding door at the
clip, push it up and snap in.
12.
Chapter 9 - Replacing Expendables466
Installing smoothing rollers
