[479] Registration charts
5. Again, print a verification chart if you want to check the results of the automatic adjustment.
6. Close the menu.
You can go to the manual adjustment settings to see the correction values that were
generated by the automatic adjustment procedure. (
Adjust media registration parameters
on
page 418)
Analyze the verification chart
[480] Two sides of the verification chart and the alignment of the circles and dots
1. Keep duplex verification chart against a light source.
2. You must see a white area between the solid dot and the circle. If the dots touch the circles,
the media registration is not correct.
Perform media registration
416
Chapter 14 - Problem Solving
