Parker AC30 series User Manual

Compliance C-16
AC30V series Variable Speed Drive
Cable Screening Bracket Kits
Frame Cable Screening Bracket Kit & Contents
Control Bracket Power Terminal Bracket C2 Ferrite Core
Frame D LA501935U001
  
Frame E LA501935U002
  
Frame F LA501935U003
  
Frame G LA501935U004
 
Frame H LA501935U005
 
Frame J LA501935U006
 
NOTE: The addition of a cable screening bracket kit to frames D, E and F drive (only) will reduce emissions from Category C3 and C2.
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
