Parker AC30 series User Manual

C-17 Compliance
AC30V series Variable Speed Drive
External AC Supply EMC Filter
WARNING
External filters are available for use with TN and IT supplies. When used on a IT supply the filter performance reduces from category C1
to Category C2. Please check for suitability on following page for External AC Supply (RFI) Filters.
Do not touch filter terminals or cabling for at least 3 minutes after removing the ac supply.
Mount the filter as close as possible to the drive.
External Filters for (Frame D, E, F & H)
They are suitable for wall or cubicle mount, but the filter must be fitted with the appropriate gland box when wall mounted.
Filter Description Filter Part Number Terminal Block Earth Terminal Dimensions Fixing Centres Weight
Frame D & E
500V IT/TN CO501894 10mm
2
M6 Stud 272 x 74 x 161mm 258 x 60mm 2.7kg
Frame F
500V IT/TN CO501895 50mm
2
M8 Stud 312 x 93 x 190mm 298 x 79mm 3.7kg
Frame H
500V IT/TN CO502672U150 70mm
2
M10 Stud 320 x 126 x 212mm 298 x 112mm 5.2kg
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
