Parker AC30 series User Manual

Installation 4-10
AC30V Variable Speed Drive
Frames E, F, G, H & J
Top Cover:
To remove insert a screwdriver into the slot and
move to the right to release the catch, and then
slide off cover.
Bottom Cover:
To remove bottom cover insert a screwdriver into the
slot and move to the left to release the catch, and
then slide off cover.
www.comoso.com

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
